Explosion-proof: Exs[ib]dI
Weather-proof
Methane alarm: Voice and light alarm
Trade Terms
1. Payment: T/T
2. Price terms: FOB Xi'an China
3. Package: With brown carton
4. Delivery: 3days for samples
5. M. O. Q: 1PCS
Item |
Specification |
Rated capacity |
5Ah |
Rated voltage |
3.7V |
Lighting time |
≥ 11h |
Main light source |
Rated voltage |
3.7V |
Rated current |
0.20A |
Maximum illuminance(1m apart from lamp) |
Lighting begins |
≥ 1000lx |
After the lighting 11h |
≥ 500 lx |
Auxiliary light source |
0.2w |
Explosion-proof type |
Exs[ib]dI |
Battery cycle life |
> 500 cycles |
Carrier catalyzing component |
Working voltage |
2.5V |
Working current |
≤ 95mA |
Alarm point (Factory setting) |
1.00%CH4 |
Alarm point error |
± 0.10%CH4 |
Dimension of headpiece |
Φ 71 × 75 |
Dimension of battery case |
71 × 40 × 110 |
Weight |
< 0.7kg |
Working environment |
1)Ambient temperature: (-10~40) degree
2)Relative humidity: ≤ 95%
3)Atmospheric pressure: (86~106)kPa
4)Can be used for high-gas coal mine |
We're a ISO9001: 2008 Certified company that develop and manufacture coal mining safety equipment with the brand name of "GOKANG" since 1995. There are more than 50 skill engineers and 100 workes. Our factory locete in Xi'an China.
Cap lamps KL1.2Ex, KL4Ex, KL6Ex have passed ATEX/CE certification, Self rescuer K-S60 got CE(EN 13794) mark. They have been export to Chile, Brazil, Colombia, Mexico, America, United Kingdom, Swedden, Spain, Turkey, Russia, Ukraine, Kazakhstan, Romania, Iran, Tanzania, Georgia, Zimbabwe, India, Philippines, Vietnam, Australian, etc.
Welcome to Shaanxi Star Coal Mine Safety Equipment Co., Ltd.
Main Products:
1. Mining cap lamp
2. Mining self rescuer
3. Mining gas detector&sensor
