| Prod Model: |
KW-S51 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Working Temperature: |
30 - 45 |
| Working Lifetime: |
50000 |
| LED Light Source: |
CREE |
| Color: |
Warm White; Cool White; Pure White |
| Place Of Origin: |
Guangdong, China (Mainland) |
| Chip: |
Bridgelux CREE Samsung Ge Osram |
| Accessories: |
Photocell, Smart Control, Dimming Driver, Surge Pr |
| Certificate: |
UL Dlc CE RoHS |
| Company Type: |
Manufacturer LED Street Lights |
| Major Markets: |
North America,South America,Europe |
| Power Supply: |
AC |
| Color Temperature: |
Pure White |
| Lamp Body Material: |
Aluminum |
| Application: |
Garden |
| IP Rating: |
IP65 |
| Certification: |
UL |
| Input Voltage: |
110v |
| With Light Source: |
With Light Source |
| LED Chips Brand: |
Bridgelux |
| Power: |
165W |
Product Description
Light Source: LED
Item Type: Street Lights
LED Light Source: Bridgelux, Epistar
Input Voltage(V): AC: 100-240V
Lamp Power(W): 165
Lamp Luminous Flux(lm): 15675
Lamp Luminous Efficiency(lm/w): 95
CRI (Ra>): 75
Color Temperature(CCT): 3000-6500K
Working Temperature(ºC): -40 - +50
Working Lifetime(Hour): 50000
Lamp Body Material: Aluminum Alloy
IP Rating: IP65
Certification: CE, FCC, RoHS
Warranty(Year): 3
Place of Origin: GUANGDONG
Brand Name: KINGWON
Model Number: KW-S51
Maximum Current: AC 1.70A -120V, 0.85A -240V
LED Driver: Mean Well
Driver Efficiency: > 90%
Power Factor (PF): > 0.95
Operating Humidity: 10% to 90%
Heat Radiator: Anodized Aluminum
Lens: PC
Fixture Dimension: 530 x395 x200 mm /20.9 x15.6 x7.9 inches
Fixture Weight: 13.1 kg /28.9 lbs
Aperture Diameter: 60 mm /2.4 inches
Datasheet
| Electrical Specifications |
| Nominal Wattage | 165W |
| Nominal Voltage | AC 100-240V, 50/60Hz |
| Maximum Current | AC 1.7A-120V, 0.85A-240V |
| Optimal Operating Temperature | - 40 ºC to 50 ºC |
| Operating Humidity | 10% to 90% |
| Power Factor (PF) | >0.9 |
| Driver Efficiency | >90% |
| Photometric Specifications |
| Correlated Color Temperature (CCT) | 3000-3500K, 4000-4500K, 5000-5500K, 6000-6500K |
| Lumen Output (3000-4500K) | 14850 lm ( +/- 5% ) |
| Lumen Output (5000-6500K) | 15675 lm ( +/- 5% ) |
| Color Rendering Index (CRI) | Ra≥75 |
| Mechanical Specifications |
| IP Rating | IP65 |
| Lifetime | 50000 hours |
| Housing | Anodized Aluminum |
| Heat Raditor | Anodized Aluminum |
| Lens | PC |
| Fixture Dimension | 530 x 395 x 200 mm / 20.9 x 15.6 x 7.9 inches |
| Fixture Weight | 11.7 kg / 25.8 lbs |
| Aperture Diameter | Φ60 mm / Φ2.4 inches |
| Packing Informations |
| Packing Type | 1 unit / ctn |
| Packing Dimension | 580 x 445 x 220 mm / 22.8 x 17.5 x 8.7 inches |
| Packing Weight | 16.1 kg / 35.5 lbs |
Features
1 | No UV | 12 | Significant energy savings |
| 2 | Long life | 13 | Wide input: 100 - 240V AC |
| 3 | Waterproof | 14 | Stable and efficient LED driver |
| 4 | Instant on/off | 15 | Significantly less generated heat |
| 5 | Mercury free | 16 | Resistant to shock and vibration |
| 6 | Maintenance free | 17 | Optimal heat sinking performance |
| 7 | Improved visibility | 18 | LED's maintain flux up to 100 lm/W |
| 8 | Ease of installation | 19 | Temperature compensation technology |
| 9 | Copper free aluminum | 20 | Exclusive appearance design with patents |
| 10 | Superior optical design | 21 | High quality and brightness LED light source |
| 11 | More than twice the average life of metal halide and high pressure sodium |
